불소도장

도장 시스템 공정 품명 건조도막두께 건조 조건
2-COAT
SYSTEM		 Primer FROPON(S) Primer 5-10 210-2161c x 5mins
FROPON(S) Flash Primer Flash-off
Top FROPON(S) Color 25-30 232-2411C xIOmins
2-COAT
PEARL
SYSTEM		 Primer FROPON(S) Primer 5-10 210-2161C x 5mins
FROPON(S) Flash Primer Flash-off
Top FROPON(S) P Color 30-35 232-241 社 xIOmins
3-COAT
SYSTEM		 Primer FROPON(S) Primer 5-10 210-216°c x 5mins
FROPON(S) Flash Primer Flash-off
Top FROPON(S)XM Color 25-30 232-241^ xIOmins
Flash-off
Clear FROPON(S) Top Clear 10-15 232-24113 xIOmins

프로폰의 도막성능

Properties Description Remarks Result
광택 60° Glass ASTM D523 Spec, ±5
연필경도 Berol Eagle Turquoise Pencil ASTM D3363 F Min.
부착성 Dry Adhesion 1mm Cross Cut ASTM D3359 100/100
Wet Adhesion 38°c, 24hrs, 1mm Cross Cut
Boiling Water Adhesion 100°c, 20mins, 1mm Cross Cut
충격성 5/8inch Diameter
0.1inch Distortion		 ASTM D2794 No Removal
내마모성 Falling Sand ASTM D968 40min.
내몰탈성 Mortar PAT 24hrs AAMA 2605 Novisual Change No Blistering
내세제성 3% Detergent, 38°c, 72hrs ASTM D2248 No  Blistering (ASTM D3359)
내유리세정성 10Drops, 24hrs
Cross-Cut		 AAMA 2605 Novisual Change
No Blistering
내산성 Muriatic Acid Resistance 10% muriaticacid, 15mins AAMA 2605 Novisual Change No Blistering
Nitric Acid Resistance 70% HNO3, 30mins ASTM D2244 △E = 5 Max
내습성 HR 100%, 38°c, 4000hrs ASTM D2247 Blister Size No.8 Max
(ASTM D714
내염수분무성 5% Salt Solution, 4000hrs ASTM B117 Scribe or Cut edges : rating 8Min
Field : rating 7Min
(ASTM D1654)
내후성 Color Retention South Florida
10years Exposure		 ASTM D2244 △E = 5 Max
Glass Retention ASTM D523 50% Min.
Chalk Resistance ASTM D659 Rating 6-8
 Resistance To Erosion ASTM B244 Film loss 10%
