HOME > 제품소개 > 쎈코트

쎈코트

도장사양

2-Coat system (2C 1B)

Substrate Pretreatment Method of
Application		 Coating
System		 Product
Name		 D.F.T
(㎛)		 Baking condition
(KEEP TIME
Aluminum Chromate Spray Primer DSS-130 7~10 SET 10min
Top NEW SSENCOAT 25~30 180℃ X 15min

3-Coat system (3C 2B)

Substrate Pretreatment Method of
Application		 Coating
System		 Product
Name		 D.F.T
(㎛)		 Baking condition
(KEEP TIME
Aluminum Chromate Spray Primer DSS-130 5~10 SET 10min
Top NEW SSENCOAT 25~30 180℃ X 15min
Clear NEW SSEN Clear 10~15 180℃ X 15min

도막성능

Description Requirement Result
광택(60º Gloss) 유,반,무광 지정광택
도막경도(Dry film hardness) 3H이상 3H
부착성 (adhesion) Dry, wet boiling water, No removal No removal
내충격성 (Impact resistance) 5/8" distortion, No removal No removal
내마모성 (abrasion resistance) abrasion coeffcient value, 40min Exceeds spec
내상성 (acid resistance) 10% Muriatic acid,
15min no visual changes		 No Blistering, No Visual change
내몰탈성 (Mortar resistance) Mortar pat, 24hr, no visual change No Visual change
내질산성(Nitric acid resistance) 70% - HNO₃ Vapor 30min
△E<5 color mac change		 5△E
내세제성 (Detergent resistance) 3% Detergent 72hrs no effect No Blistering, No Visual change
내습성 (Humidity resistance) RH 100%, 38℃, 3000hrs Blister
not to exceed No.8		 No Blistering
내염수분무성 (Salt spray resistance) 5% salt 3000hr, minimum 7
rating on scribe or cut rating of 8
and minimum blister rating of 8		 No Blistering
총진내후성
(Accelerated
weathering
resistance)		 W.O.M (3,000시간)
광택보존성 (Gloss retention)		 △E<5
85% 이상		 △E<5
85%
Q.U.V (3,000시간)
광택보존성 (Gloss retention)		 △E<5
85% 이상		 △E<5
85%
